OPEN SLOT WIRING DUCT WITH SCORE LINE

● Material: UL94V-0 flame rated, UL approved PVC. ● Color: Grey. ● PVC service temperature: 85℃ ● UL Test up to 50℃ ● 4.5mm SLOT with score line. ※ The standard wiring duct can be available for non-slip cover, suitable for vertical installations. The item number please specify for example, Item no. ：GD-3060SQ → GQ-3060SQ Non-slip cover for the size less than 20mm width or bigger than 125mm is available upon request.

Part No.	Size WxH	Length
Slot (4.5mm)	Size mm
GD-3060SQ	30x 60	2M
GD-4060SQ	40x 60
GD-6060SQ	60x 60
GD-8060SQ	80x 60
GD-10060SQ	100x 60
GD-12060SQ	120x 60

Part No.	Size WxH	Length
Slot (4.5mm)	Size mm
GD-3080SQ	30x 80	2M
GD-4080SQ	40x 80
GD-6080SQ	60x 80
GD-8080SQ	80x 80
GD-10080SQ	100x 80
GD-12080SQ	120x 80
