PCB SUPPORT

● Material: UL94V-2 flame rated, UL approved Nylon 66. ● Color: Natural

Part No.	H1	P.C.B		Chassis		Packing
		Hole	Thickness	Hole	Thickness
		M1	T1	M2	T2
MCS-6	6.0	4.0	1.8	4.8	2.0	100 pcs / Bag

Part No.	H1	P.C.B		Chassis		Packing
		Hole	Thickness	Hole	Thickness
		M1	T1	M2	T2
MCS-8	7.8	4.0	1.7	4.8	5.0	100 pcs / Bag

Part No.	H1	P.C.B		Chassis		Packing
		Hole	Thickness	Hole	Thickness
		M1	T1	M2	T2
MCS-9	9.4	4.0	1.6	4.8	2.0	100 pcs / Bag

Part No.	H1	P.C.B		Chassis		Packing
		Hole	Thickness	Hole	Thickness
		M1	T1	M2	T2
MCS-12	11.5	4.0	1.7	4.8	5.0	100 pcs / Bag

Part No.	H1	P.C.B		Chassis		Packing
		Hole	Thickness	Hole	Thickness
		M1	T1	M2	T2
MCS-19	19.0	4.0	2.0	4.8	2.0	100 pcs / Bag
