PCB SUPPORT

● Material: UL94V-2 flame rated, UL approved Nylon 66. ● Color: Natural

Part No.	H1	H2	P.C.B		Chassis		Packing
			Hole	Thickness	Hole	Thickness
			M1	T1	M2	T2
SPA-28	28.2	3.6	3.6	1.6	3.8	1.6	100 pcs / Bag

Part No.	H1	H2	P.C.B		Chassis		Packing
			Hole	Thickness	Hole	Thickness
			M1	T1	M2	T2
SPB-6	6.2	5.5	4.0	1.8	4.0	1.8	100 pcs / Bag
SPB-20	20.0	5.5	4.0	1.8	4.0	1.8

Part No.	H1	H2	P.C.B		Chassis		Packing
			Hole	Thickness	Hole	Thickness
			M1	T1	M2	T2
SPC-9	9.3	4.0	4.0	1.6	4.0	1.6	100 pcs / Bag

Part No.	H1	H2	P.C.B		Chassis		Packing
			Hole	Thickness	Hole	Thickness
			M1	T1	M2	T2
SPD-9	9.5	5.5	3.5	1.8	3.5	1.8	100 pcs / Bag
