LED HOLDER

● Material: UL94V-2 flame rated, UL approved Nylon 66. ● Color: Black.

Part No.	Dimension									Packing
	L	L1	W	H	H1	H2	P1	P2	LED
PLD1-3A	6.5	2.0	4.7	7.5	5.05		4.65		3Φ 2 PIN	100 pcs / Bag

Part No.	Dimension									Packing
	L	L1	W	H	H1	H2	P1	P2	LED
PLD2-3A	9.2	2.8	4.5	10.0	2.70	5.0	4.90	7.2	3Φ 2 PIN	100 pcs / Bag

Part No.	Dimension									Packing
	L	L1	W	H	H1	H2	P1	P2	LED
PLD2-3B	8.2	2.6	4.8	9.9	2.60	5.0	4.80	7.2	3Φ 2 PIN	100 pcs / Bag

Part No.	Dimension									Packing
	L	L1	W	H	H1	H2	P1	P2	LED
PLD2-5C	11.2	4.5	5.9	12.2	2.95	6.3	5.60	7.7	5Φ 2 PIN	100 pcs / Bag

Part No.	Dimension									Packing
	L	L1	W	H	H1	H2	P1	P2	LED
PLD4-3A	10.2	1.0	10.2	10.2	2.60	5.0	6.40	9.2	3Φ 2 PIN	100 pcs / Bag

Part No.	Dimension									Packing
	L	L1	W	H	H1	H2	P1	P2	LED
PLD4-3B	20.4	4.4	22.7	9.0	5.60		15.00		3Φ 2 PIN	100 pcs / Bag
